DC SURGE ARRESTER

DC SURGE ARRESTER DC surge arresters have wide usage areas especially in solar power plants, telecom sector and data systems and security systems. DC surge arresters, which have a wide range of applications from 12V to 1500V, are produced on the same board as AC surge arresters with the Trimbox brand, providing financial savings of 2/3 in terms of consumers. 12V-1500V DC Surge Arresters System DC Earth Connection Available Protection mode (+)-PE, (-)-PE, (+)-(-) Imax 12,5kA (10/350 µs) In 20kA (8/20 µs) Itotal 50kA (8/20µs) Response Time (+)-PE, (-)-PE, (+)-(-) ≤ 10ns Inlet Connection Screw Clamp No Output Connection Multi-core and Single-Core conductor cross-section 2.5 mm2, 4 mm2 Protection class IP20 Enclosure material White ABS, UL’94 V-0 Non-Flammability grade Standards/Regulations EN 50539-11:2013+A, EN 50539-11:2013+A1:2014 Standards for clearances and scattering distances DIN VDE 0110-1, IEC 60664-1 Faulty message for overvoltage protection 1 Adet LED Direction of movement (+)-PE, (-)-PE, (+)-(-) Mounting type, Design DIN rail 35mm, Rail module Ambient temperature -50°C, +80°C Dimensions 50 x 75 x 60mm
